Specification parameters

Product name

Model number

IdeaHub B3-G

65": IHB3-65SU
75": IHB3-75SU
86": IHB3-86SU

Product size (unit: mm)

Package size (L x W x H) (in mm)

Weight (net/gross weight including package)

65": 1484.5 x 91.6 x 916.1
75": 1705.7 x 91.8 x 1040.5
86": 1953.0 x 91.8 x 1180.6

65": 1650 x 220 x 1050
75": 1900 x 220 x 1170
86": 2090 x 250 x 1300

65": 35.5kg; 43.0kg75
": 47.8kg; 57.8kg86
": 63.0kg; 74.5 kg

module

Complete machine

Stylus

Matching cable

1 set

2 pieces

1 power cord

Smart screen projector

Floor stand

Wall brackets

Optional (Type-C/Type-A interface)

Optional (65", 75", 86" universal)

Optional (65", 75", 86" general)

Screen

Resolution

Type of backlight

Bonding process

Color gamut

4K

D-LED

Zero fit

85%NTSC

Video camera

Lens zoom

Maximum viewing Angle

Resolution

TV distortion

Smart Director

2x digital zoom

Horizontal: 80%/ Vertical: 50°

4K

<2%

Support

loudspeaker

Frequency domain

Number of speakers

Maximum power

100Hz- 20kHz

4

30W

Microphone

Pickup Angle

Number of microphones

Pickup distance

180°

6

10m

Wireless connection

Dual wi-fi modules

Frequency

NFC

wifi5+wifi6

2.4GHz + 5GHz

Support

System

CPU

RAM

Flash

Operating system

8 cores

8GB

64GB*

HarmonyOs/Windows(OPS optional)

Meetings

Adaptation meeting

Meeting effects

Meetings: Huawei Cloud Conference SmartRooms, Huawei Cloud WeLink
conference APP: Tencent conference Rooms, Feishu conference room

Conference: Huawei Cloud Conference SmartRooms, Huawei Cloud WeLink:1080P30fps video
conference APP: Tencent conference Rooms:1080P video, Feishu conference room: 720P video

Writing

Writing delay

Whiteboard preservation method

Intelligent writing recognition

Touch height

16ms

Scan code/mail/local/USB flash drive

Support

The 1.5 mm

Interface

Front interface

Side port

Type-C x 1

USB 3.0x 1

HDMI OUT x 1

3.5mm Line-outx 1

RJ45x1 (10/100/1000M LAN)

USB 3.0 x 2

HDMI IN x 2

COMx 1

3.5mm Line-in x 1
