System Compatibility

Projection receiving end

Available with IdeaHub Enterprise, IdeaHub Pro, IdeaHub S, IdeaHub Board Pro, IdeaHub B2-G, IdeaHub B3-G, IdeaHub Board 2-G, IdeaHub Board 3-G, IdeaHub S2-G, IdeaHub S2 Pro-G, IdeaHub ES2-G, IdeaHub ES2 Pro-G, IdeaHub ES2 Plus-G, Collaboration Device Pro, Collaboration Device, Collaboration Device Lite, Box 310-G, Box610-G

Projection Side Operating System *

Support Windows, MacOS, Android, HarmonyOS, iOS

Video Features

Projection Resolution

Up to 1080P60FPS when free installation, up to 4K30FPS after APP installation

Audio Features

Screen Audio

Supports 48K dual-channel lossless audio

Safety and Stability

Connection Distance

≤20 meters

Data Security

AES encryption

Interface

Type

Type-C interface that can be converted toUSB Type-A

Wireless Parameters

Protocol

Support 802.11a /b/g/ac

Wi-Fi Frequency

2.4GHz and 5GHz

Modes

Support Client mode

Authentication Mode

Supports WPA2-PSK authentication

Physical Specifications

Dimensions

(L × W × H)

Product size: 154mm × 60mm × 18mm

Packing size: 175mm × 115mm × 32mm

Weight

Gross weight: 162.5g

Net weight: 58.59g

Maximum Power Consumption

≤ 2.5 W

Operating Voltage

5VDC

Ambient Temperature and Humidity

Ambient temperature:

Working condition: 0℃ to 40℃

Non-working state: -40℃ to +70℃

Ambient relative humidity (non-condensing):

Working condition: 5% to 95%

Non-working state: 0% to 95%

Certification and Standards

Eu CE certification, China wireless model approval
