Product Appearance

Description

CloudEngine S5735-S24T4XE-V2-G

24*10/100/1000BASE-T Ethernet ports, 4*10-gigabit SFP+, 2*dedicated stack ports
Support for 1+1 power backup
Packet Forwarding Rate: 171Mpps
Exchange Capacity: 672Gbps/6.72Tbps

CloudEngine S5735-S24P4XE-V2-G

24*10/100/1000BASE-T Ethernet ports, 4*10-gigabit SFP+, 2*dedicated stack ports
Support 3 power supplies, N+1 power backup
PoE+
Packet Forwarding Rate: 171Mpps
Exchange Capacity: 672Gbps/6.72Tbps

CloudEngine S5735-S24U4XE-V2-G

24*10/100/1000BASE-T Ethernet ports, 4*10-gigabit SFP+, 2*dedicated stack ports
Support 3 power supplies, N+1 power backup
PoE++ (90W)
Packet Forwarding Rate: 171Mpps
Exchange Capacity: 672Gbps/6.72Tbps

CloudEngine S5735-S48T4XE-V2-G

48*10/100/1000BASE-T Ethernet ports, 4*10-gigabit SFP+, 2*dedicated stack ports
Support for 1+1 power backup
Packet Forwarding Rate: 207Mpps
Exchange Capacity: 672Gbps/6.72Tbps

CloudEngine S5735-S48T4XE-XA-V2-G

48*10/100/1000BASE-T Ethernet ports, 4*10-gigabit SFP+, 2*dedicated stack ports
Built-in dual AC power supply, support power 1+1 backup
Packet Forwarding Rate: 207Mpps
Exchange Capacity: 672Gbps/6.72Tbps

CloudEngine S5735-S48P4XE-V2-G

48*10/100/1000BASE-T Ethernet ports, 4*10-gigabit SFP+, 2*dedicated stack ports
Support for 3 power supplies, N+1 power backup
PoE+
Packet Forwarding Rate: 207Mpps
Exchange Capacity: 672Gbps/6.72Tbps

CloudEngine S5735-S48U4XE-V2-G

48*10/100/1000BASE-T Ethernet ports, 4*10-gigabit SFP+, 2*dedicated stack ports
Support for 3 power supplies, N+1 power backup
P ++ (90W)
Packet Forwarding Rate: 207Mpps
Exchange Capacity: 672Gbps/6.72Tbps

Items

CloudEngine S5735- S48T4XE-V2-G

CloudEngine S5735- S48T4XE-XA-V2-G

CloudEngine S5735- S48P4XE-V2-G

CloudEngine S5735- S48U4XE-V2-G

Fixed Port

48*10/100/1000BASE-T to Ethernet ports

4*10-gigabit SFP+

2*dedicated stacking port

48*10/100/1000BASE-T to Tai-net port

4*10-gigabit SFP+

2*special stacking port

48*10/100/1000Base-T ports(PoE+)

4*Gigabits SFP+

2*dedicated stacking ports

48*10/100/1000BASE-T to Ports (PoE++)

4*tens of thousands Megabyte SFP+

2*dedicated stacking ports

Chassis Dimensions

(W × D × H)

442mm × 420mm × 43.6mm

442mm × 420mm × 43.6mm

442mm × 420mm × 43.6mm

442mm × 420mm × 43.6mm

Chassis Height

1U

1U

1U

1U

Weight of the Whole Machine (including packing materials)

7.74kg

7.74kg

8kg

8.02kg

Expansion Slot

NA

NA

NA

NA

Power Supply Type

80W AC power supply

180W AC power supply

600W AC power supply

1200W DC power supply

Built-in dual AC power supply, support power supply 1+1

Backup

600W AC PoE power supply

1000W AC PoE power supply

1000W DC PoE power supply

600W AC PoE power supply

1000W AC PoE power supply

1000W DC PoE power supply

Maximum Power Consumption

55.12W

(with 2 80W AC Psus)

64.51W

(with 2 180W AC power modules)

93.26W

(with 2 1200W DC power module)

55.12W

(with 2 80W AC power modules)

64.51W

(with 2 180W AC power modules)

93.26W

(with 2 1200W DC power module)

Without PoE: 71.45W

(With 2 600W AC power modules)

With PoE: 1931.44W

(PoE: 1680W with 3 1000W Psus)

Without PoE: 71.95W

(With 2 600W AC power modules)

With PoE: 3117.0W

(PoE: 2880W, With three 1000W source module)

Long Run Temperature

0-1800m altitude:

-5℃ to +50℃

1800-5000m altitude:

the operating temperature drops by 1℃

for every 220m increase in altitude

0-1800m altitude:

-5℃ to +50℃

1800-5000 m altitude:

the operating temperature decreases by

1 degree Celsius for every 220m increase in altitude

0-1800m altitude:

-5℃ to +50℃

1800-5000 m altitude:

the operating temperature decreases by

1 degree Celsius for every 220m increase in altitude

0-1800m altitude:

-5℃ to +50℃

1800-5000m altitude:

the operating temperature decreases by

1 degree Celsius for every 220m increase in altitude

Storage Temperature

-40℃ to 70℃

-40℃ to 70℃

-40℃ to 70℃

-40℃ to 70℃

Relative Humidity

5% to 95%RH

 (no condensation)

5% to 95%RH

 (no condensation)

5% to 95%RH

 (no condensation)

5% to 95%RH

 (no condensation)

Service Port Lightning Protection

Common mode ±10kV

Common mode ±10kV

Common mode ±10kV

Common mode ±10kV

Power Port Lightning Protection

AC power port:

differential mode ±6kV, common mode ±6kV

AC power port:

differential mode ±6kV, common mode ±6kV

AC power port:

differential mode ±6kV, common mode ±6kV

AC power port:

differential mode ±6kV, common mode ±6kV

DC power port:

differential mode ±2kV, common mode ±4kV

DC power port:

differential mode ±2kV, common mode ±4kV

DC power port:

differential mode ±2kV, common mode ±4kV

DC power port:

differential mode ±2kV, common mode ±4kV

Heat Dissipation Mode

Air cooling heat dissipation, intelligent speed regulation

Air cooling heat dissipation, intelligent speed regulation

Air cooling heat dissipation, intelligent speed regulation

Air cooling heat dissipation, intelligent speed regulation

Items

CloudEngine S5735-S24T4XE-V2-G

CloudEngine S5735- S24P4XE-V2-G

CloudEngine S5735-S24U4XE- V2-G

Fixed Port

24*10/100/1000BASE-T to Ethernet ports

4*gigabits SFP+

2*dedicated stack ports

24*10/100/1000BASE-T to Ethernet port (PoE+)

4*10-gigabit SFP+

2*dedicated stack ports

24*10/100/1000BASE-T Ethernet port (PoE++)

4*10 gigabit SFP+

2*dedicated stacking ports

Chassis Dimensions

(W×D × H)

442mm × 420mm × 43.6mm

442mm × 420mm × 43.6mm

442mm × 420mm × 43.6mm

Chassis Height

1U

1U

1U

Weight of the Whole Machine (including packing materials)

7.48kg

7.74kg

7.82kg

Expansion Slot

NA

NA

NA

Power Supply Type

80W AC power supply

180W AC power supply

600W AC power supply

1200W DC power supply

600W AC PoE power supply

1000W AC PoE power supply

1000W DC PoE power supply

600W AC PoE power supply

1000W AC PoE power supply

1000W DC PoE power supply

Maximum Power Consumption

33.1W

(with 2 80W AC Psus)

45.75W

(with 2 180W AC power modules)

85.2W

(with 2 1200W DC power modules)

Without PoE: 49.9W

(With 2 600W AC power modules)

With PoE: 1023.22W

(PoE: 840W with 3 1000W power modules)

Without PoE: 55.2W

(With 2 600W AC power modules)

With PoE: 2430.11W

(PoE: 2268W with 3 1000W power modules)

Long Run Temperature

0-1800m Altitude: -5℃ to +50℃

0-1800m altitude: -5℃ to +50℃

0-1800m altitude: -5℃ to +50℃

1800-5000m altitude:

the operating temperature decreases by 1℃ for every increase of 220m in altitude

1800-5000m altitude:

the operating temperature decreases by 1℃ for every 220m increase in altitude

1800-5000m altitude:

the operating temperature decreases by 1℃ for every 220m increase in altitude

Storage Temperature

-40℃ to 70℃

-40℃ to 70℃

-40℃ to 70℃

Relative Humidity

5% to 95%RH (no condensation)

5% to 95%RH (no condensation)

5% to 95%RH (no condensation)

Service Port Lightning Protection

Common mode ±10kV

Common mode ±10kV

Common mode ±10kV

Power Port Lightning Protection

AC power port:

differential mode±6kV, common mode ±6kV

AC power port:

differential mode ±6kV, common mode ±6kV

AC power port:

differential mode ±6kV, common mode ±6kV

DC power port:

differential mode ±2kV, common mode ±4kV

DC power port:

differential mode ±2kV, common mode ±4kV

DC power port:

differential mode ±2kV, common mode ±4kV

Heat Dissipation Mode

Air cooling heat dissipation, intelligent speed regulation

Air cooling heat dissipation, intelligent speed regulation

Air cooling heat dissipation, intelligent speed regulation

Model

CloudEngine S5735-S-X-G Series Switch

S5735-S24T4X-X-G

S5735-S24T4X-X-G(24*10/100/1000BASE-T Ethernet ports,4*10-gigabit SFP+, power not included)

Model

CloudEngine S5735-S-V2-G Series Switch

S5735-S24T4XE-V2-G

S5735-S24T4XE-V2-G(24*10/100/1000BASE-T Ethernet ports,4*10-gigabit SFP+,2*12GE stack ports, no power)

S5735-S24P4XE-V2-G

S5735-S24P4XE-V2-G(24*10/100/1000BASE-T Ethernet ports,4*10-gigabit SFP+,2*12GE stack ports,PoE+, no power)

S5735-S24U4XE-V2-G

S5735-S24U4XE-V2-G(24*10/100/1000BASE-T Ethernet ports,4*10-gigabit SFP+,2*12GE stack ports,PoE++, without power)

S5735-S24ST4XE-V2-G

S5735-S24ST4XE-V2-G(24*Gigabit SFP, including 8 10/100/1000Base-T Combo,4*10-gigabit SFP+,2*12GE stack ports, no power)

S5735-S24HS4XE-V2-G

S5735-S24HS4XE-V2-G(24*photoelectric combination ports

(24*Gigabit SFP,24 PoE++ ports (DB50)),4*10-gigabit SFP+,2*12GE stack ports, without power)

S5735-S24PN4XE-V2-G

S5735-S24PN4XE-V2-G(24*10/100/1000/2.5GBASE-T Ethernet ports (PoE+),4*10-Gigabit SFP+,2*12GE stack ports, without power supply)

S5735-S48T4XE-V2-G

S5735-S48T4XE-V2-G(48*10/100/1000BASE-T Ethernet ports,4*10-gigabit SFP+,2*12GE stack ports, no power)

S5735-S48P4XE-V2-G

S5735-S48P4XE-V2-G(48*10/100/1000BASE-T Ethernet ports,4*10-gigabit SFP+,2*12GE stack ports,PoE+, no power)

S5735-S48U4XE-V2-G

S5735-S48U4XE-V2-G(48*10/100/1000BASE-T Ethernet ports,4*10-gigabit SFP+,2*12GE stack ports,PoE++, without power)

S5735-S48S4XE-V2-G

S5735-S48S4XE-V2-G(48*Gigabit SFP,4*10-Gigabit SFP+,2*12GE stack ports, no power)

S5735-S48HS4XE-V2-G

S5735-S48HS4XE-V2-G(48*photoelectric combination ports

(48*Gigabit SFP,48 PoE++ ports (DB50)),4*10-gigabit SFP+,2*12GE stack ports, without power)

S5735-S48PN4XE-V2-G

S5735-S48PN4XE-V2-G(48*10/100/1000/2.5GBASE-T Ethernet ports (PoE+),4*10-Gigabit SFP+,2*12GE stack ports, no power)

Model

CloudEngine S5735I-S-V2-G Series Industrial Switch (Rack model)

S5735I-S16T8S4XE-QD-V2-G

S5735I-S16T8S4XE-QD-V2-G

(16*10/100/1000BASE-T Ethernet ports,8*Gigabit SFP,4*10-Gigabit SFP+,2*12GE stack ports, dual DC 18-60V power supply, no fan)

S5735I-S24T8S4XE-QA-V2-G

S5735I-S24T8S4XE-QA-V2-G

(24*10/100/1000BASE-T Ethernet ports,8*Gigabit SFP,4*10-Gigabit SFP+,2*12GE stack ports, dual AC power, no fan)

Model

CloudEngine S5735I-S-V2-G Wide Temperature Series Switch (Cabinet type)

S5735I-S24T4XE-V2-G

S5735I-S24T4XE-V2-G(24*10/100/1000BASE-T Ethernet ports,4*10-gigabit SFP+,2*12GE stack ports, no power)

S5735I-S24U4XE-V2-G

S5735I-S24U4XE-V2-G(24*10/100/1000BASE-T Ethernet ports,4*10-gigabit SFP+,2*12GE stack ports,PoE++, without power)
