CloudEngine S6730-H-G

The CloudEngine S6730-H-G series switches are 10G, 25G, 40G and 100G Ethernet switches designed for campus networks. The rich port types meet diverse network bandwidth requirements. The products support cloud management, and realize the full life cycle cloud management network services including planning, deployment, monitoring, experience visualization, fault repair and network optimization, so that network management is simple. The product supports on-board AC capability, integrates AC function, and can manage large-scale aps, effectively simplifying the customer's network architecture and the number of devices, and reducing the networking cost. The product has the ability to travel business and realize the unified identity information of the whole network. No matter where the user accesses from, they can enjoy the same rights and user experience, and fully meet the requirements of enterprise mobile office. The product supports VXLAN technology to realize service isolation through network virtualization and multi-purpose of one network, greatly improving network capacity and utilization. This series of switches is the best choice for the new generation of iot converged network in terms of cost, flexibility, and scalability. The whole series of products have built-in security probe, support abnormal traffic detection, threat analysis of encrypted traffic, and the whole network threat trapping and other functions, which has changed from the traditional passive defense to the active defense, effectively ensuring the security of the campus network.

Technical Specification

Product Appearance

Description

CloudEngine S6730-H48X6C-G

48*10-gigabit SFP+, 6*40/100GE QSFP28

Pluggable dual power supply with 1+1 backup

Packet Forwarding Rate: 1620Mpps

Switching Capacity: 2.56T/25.6Tbps

Instructions

The 100GE QSFP28 interface supports 40GE and 100GE optical module self-adaptation

The uplink port is 40GE by default and needs to be upgraded to 100GE by License

CloudEngine S6730-H24X6C-G

24*10-gigabit SFP+ and 6*40/100GE QSFP28

Pluggable dual power supply, support 1+1 backup

Packet Forwarding Rate: 1260Mpps

Exchange Capacity: 2.56T/25.6Tbps

Instructions

The 100GE QSFP28 interface supports 40GE and 100GE optical module self-adaptation

The uplink port is 40GE by default and needs to be upgraded to 100GE by License

Technical Specification

Items	CloudEngine S6730- H48X6C-G	CloudEngine S6730- H24X6C-G
Fixed Port	4810 gigabit SFP+ 640/100GE QSFP28	2410-gigabit SFP+ 640/100GE QSFP28
Chassis Dimensions (W × D × H)	442mm × 420mm × 43.6mm	442mm × 420mm × 43.6mm
Chassis Height	1U	1U
Typical Power Consumption	165W	149W
Maximum Power Consumption	291W	254W
Operating Temperature	-5℃ to +45℃ (0m to 1800m altitude) Instructions 1800m to 5000m, the maximum temperature specification is reduced by 1℃ for every 220m increase in altitude. The device cannot be started when the ambient temperature is lower than 0℃.
Storage Temperature	-40℃ to +70℃
Service Port Lightning Protection	Common mode ±10kV
Power Port Lightning Protection	AC power module: differential mode ±6kV, common mode ±6kV
	DC power modules: differential mode ±2kV, common mode ±4kV
Power Supply Type	600W AC power module
	1000W DC power module
	NOTE There are two power supply modes: single power supply and dual power supply. When the two power supplies are used, the power supply to the host is in 1+1 redundancy backup mode. The pluggable AC and DC power modules can be configured on the same device at the same time
Relative Humidity	5%-95%RH (no condensation)
Number of Fans	4 fans with swappable fans
Heat Dissipation Mode	Air cooling heat dissipation, intelligent speed regulation

Full Range of S6730-H-G Silent Models

Model	CloudEngine S6730-H-G Full-featured 10-Gigabit Routing Switch
S6730-H28Y4C-G	S6730-H28Y4C-G(2825GE SFP28,4100GE QSFP28, without power supply)
S6730-H24X6C-G	S6730-H24X6C-G(2410-gigabit SFP+ 640GE QSFP28 Optional license upgrade to 6*100GE QSFP28 without power supply)
S6730-H48X6C-G	S6730-H48X6C-G(4810-gigabit SFP+,640GE QSFP28, optional license upgrade to 6*100GE QSFP28, without power)

* The descriptions and information displayed in the product promotional materials are for reference only. The actual delivered product shall prevail. The final interpretation right belongs to GLORY.
