Items

Description

Physical parameters

Dimensions (diameter x height)

Φ220 x 51mm

Weight

1.15 kg

Interface

1 x100/1000M/2.5G/5GE electrical port
1 x 10/100M/GE electrical port
1 x USB
port The 5GE electrical port supports PoE input.

IoT Expansion module

Built-in iot slot (PCIE interface) to support PCIE cards such as ZigBee/RFID/Thread

BLE

BLE5.2

LED

Indicates the system power-on status, startup status, operating status, and alarm and fault status

Power Supply Parameters

Power input

DC: 42.5V ~ 57VPoE
power supply: meet the 802.3at/bt power over Ethernet standard

POE power supply mode

2.4 GHzw

5GHz

Power consumption (excluding USB, IoT)

802.3 bt

4x4 (RTU)

4x4 (RTU)

28.8 W.

2x2 (RTU)

2x2+4x4 (RTU)

(PoE++)

2x2 (default)

4x4 (default)

< 25.5 W.

2x2 (default)

2x2+2x2 (default)

802.3at (PoE+)

4x4 (RTU)

4x4 (RTU)

< 25.5 W.

2x2 (RTU)

2x2+4x4 (RTU)

2x2 (default)

4x4 (default)

2x2 (default)

2x2+2x2 (default)

Note
For 802.3at (PoE+), the port rate is limited, 5GE is reduced to 2.5 GE, and the GE port is unavailable. The actual maximum power consumption of Ethernet ports,
IoT, USB, and bandwidth in different power supply modes
varies according to the laws and regulations of different countries and regions.

Environmental parameter

Operating temperature

-10℃~ +50℃
indicates that
the local temperature of the shell may be higher than the working temperature, but it will not affect the use of the safety standard range.

Storage temperature

-40℃~ +70℃

Operating humidity

5% to 95% (non-condensing)

Altitude

- 60m to 5000m

Working air pressure

53kPa ~ 106kPa

Rf parameters

Antenna type

Built-in smart antenna

Antenna gain

2.4GHz: 4.5dBi

5GHz: 5.5dBi
Description
1. The above gain is the peak gain of a single antenna.
2. After combining all antennas of 2.4GHz or 5GHz, equivalent antenna gain: 2.4GHz: 3dBi, 5GHz: 4dBi.

Maximum number of SSIDs per RF

≤16

Maximum number of users

≤1024 (Dual-RF mode) (512/ RF)
≤1152 (triple-RF mode) (128(2.4G RF)+512(5G RF 1)+512(5G RF 2)) The actual number of users varies according to the
usage
environment.

Max. Transmit power

2.4GHz: 26dBm (combined power)
5GHz: 26dBm (combined power)
NOTE
The actual transmit power varies according to national and regional regulations.

Power adjustment step size

1dBm
