Items

Description

Physical parameters

Size (diameter×height)

Φ220 x 51mm

Weight

1.09 kg

Interface

1 x 10M/100M/1GE electrical port (PoE input supported)

1 x 10M/100M/1GE electrical port

1 x USB2.0 port

IoT Extensions

Built-in iot slot (PCIE interface, support 2 small cards or 1 large card), can support

PCIE cards such as ZigBee/RFID/Thread

BLE

BLE 5.2

LED indicator

Indicates the system power-on status, startup status, operating status, and alarm and fault status

Power Supply Parameters

Power input

DC: 12V±10%

PoE power supply: Meets the 802.3at/af Power over Ethernet standard

Instructions

At 802.3af, AP has limitations, such as USB not being available

Maximum power consumption

≤12.63 W (excluding USB)

Instructions

The actual maximum power consumption varies according to national and regional regulations.

Environmental Parameters

Operating temperature

-10℃~ +50℃

Storage temperature

-40℃~ +70℃

Operating humidity

5% to 95% (non-condensing)

Working pressure

53kPa ~ 106kPa

Rf parameters

Antenna type

Built-in smart antenna

Antenna gain

2.4GHz: 4dBi

5GHz: 5dBi

Instructions

1. The above gain is the single antenna peak gain.

2. After combining all antennas of 2.4GHz or 5GHz, equivalent antenna gain: 2.4GHz: 2dBi, 5GHz: 3dBi.

Maximum SSID number per RF

≤16

Maximum number of users

≤1024 (512/ RF)
