Device Parameters

Operating temperature

0°C to 40°C

Operating humidity

5% RH to 95% RH (non- condensing)

Power adapter input

100–240 V AC, 50/60 Hz

System power supply

12 V DC, 1.5A

Static power consumption

5.5 W

Maximum power consumption

17 W

Dimensions (H x W x D)

200 mm x 165 mm x 36 mm (without bracket)

Memory

128 MB Flash, 256 MB RAM

Surge Protection Specifications

AC power supply: 6 kV in common mode and 4 kV in differential mode

ETH: 2.5kV in common mode

POTS: common mode: 2.5kV

Interface Parameters

GPON port

POTS port

Class B+

Receiver sensitivity: -27dBm

Overload optical power: -8 dBm

Wavelengths: 1310nm upstream, 1490 nm downstream

Wavelength blocking filter (WBF) of G.984.5

Flexible mapping between GEM Port and TCONU

Authentication mode: Password

Bi-directional FEC

SR-DBA and NSR-DBA

Type B

(single-homing&dual-homing)

Maximum ringer equivalence number (REN): 4

G.711A/μ, G.729a/b and G.722 encoding/decoding

T.30/T.38/G.711 fax mode

DTMF

Emergency calls (with the SIP protocol)

USB port

usb

FTP-based network storage

File/Print sharing based on SAMBA

DLNA function

WLAN

Ethernet port

IEEE 802.11b /g/n/ax (2.4GHz)

IEEE 802.11a /n/ac/ax (5GHz)

2 × 2 MIMO (2.4GHz&5GHz)

Antenna gain: 2 dBi

Maximum number of SSIDs on the radio: 4

Maximum number of users on the radio: A maximum of

64 per frequency band

Maximum transmit power on the radio: 27dBm(2.4GHz), 27dBm(5GHz)

WMM (Wi-Fi Multi Media), Multiple SSIDs, WPS

2.4GHz&5GHz concurrent

Air interface rate: 574 Mbit/s (2.4GHz), 2402 Mbit/s (5GHz)

Beamforming

Band steering

DL OFDMA

DL MU-MIMO

1024QAM

160MHz frequency bandwidth l DCM

BSS Coloring

WPA3

Ethernet port-based VLAN tags and tag removal

1:1 VLAN, N:1 VLAN, or VLAN transparent transmission

QinQ VLAN

Limit on the number of learned MAC addresses

MAC address learning

Auto-adaptive 10 Mbit/s, 100 Mbit/s or 1000 Mbit/s

Smart interconnection

Smart service

Smart O&M

Common O&M

Smart Wi-Fi coverage

SIP/H.248 auto-negotiation

Any port any service

Parental control

Anti-squatter

Scheduled Wi-Fi shutdown

Smart Wi-Fi sharing:

Portal / 802.1 x

authentication; SoftGRE- based sharing

IPTV video quality diagnosis

eMDI

Rogue ONU detection and isolation from the  OLT

Call emulation, and circuit test and loop-line test

PPPoE/DHCP simulation testing

One-click diagnosis (Web)

OMCI/Web UI/TR069

Variable-length OMCI messages

Dual-system software backup and rollback

Multicast

Security

QoS

Layer 3 features

IGMP v2/v3 proxy/snooping

MLD v1/v2 snooping

SPI firewall

Filtering based on

MAC/IP/URL addresses

Supports 802.1X authentication

ONU Port-Level Hard- Isolated

Ethernet port rate limitation

802.1p priority

SP/WRR/SP+WRR

Broadcast packet rate limitation

PPPoE/Static IP/DHCP

NAT/NAPT

Port forwarding

ALG, UPnP

DDNS/DNS

server/DNS client

IPv6/IPv4 dual stack, DS-Lite and IPv6 SPI

Static/Default routes

Multiple services on one WAN port

Power saving

Indicator power saving

COC V8

Network management

Visualized network management

User-defined bandwidth allocation

Wi-Fi optimization & Wi-Fi roaming

Wi-Fi O&M

Intelligent identification and anti-interference

Tunnel data forwarding using control and provisioning of wireless access points (CAPWAP) in FIT mode

Centralized Wi-Fi 6 ONU management and maintenance using the built-in AC of an OLT in FIT mode

WLAN Security

Open system authentication

WEP authentication/encryption is supported. The encryption word length is 64-bit or 128-bit

WPA2-PSK authentication/encryption (WPA2 Personal Edition)

Connected to 802.1 X authentication/encryption (connected Enterprise Edition)

WPA3-SAE authentication and encryption (WPA3 personal edition)

WPA3 802.1 X authentication/encryption (WPA3 Enterprise Edition)

Supports WPA-WPA2 hybrid authentication. Supports WPA2-WPA3 hybrid authentication

Supports 802.1X authentication, and MAC address authentication

Supports Wi-Fi management frame encryption
