Complete System components

Hd codec (built-in HD camera, array microphone), remote control, Touch touchscreen (optional), cable and power supply

Communication protocol

Multimedia framework protocol

ITU-T H.323, IETF SIP

Video codec protocol

H.265, H.265 SVC, H.264 HP, H.264 BP, H.264 SVC, H.263, H.263+

Audio codec protocol

OPUS, AAC-LD, G.729A, G.722, G.722.1C, G.711U, G.711A

Auxiliary stream protocol

ITU-T H.239, IETF BFCP

Other communication protocols

H.225, H.235, H.241, H.245, H.350, H.460, RFC2833, LDAP

Network Transport Protocol

TCP/IP, RTP, RTCP, DHCP, DNS, SMTP, SNMP, SNTP, SSH, HTTP,

Wi-Fi standards

IEEE802.11a/b/g/n/ac, WPA, WPA2

Stable security

Network adaptability

IPV4 and IPV6, Super Strong Error correction (SEC), Packet loss Retransmission (ARQ), Video Forward error correction (FEC), Audio Backward Error Correction (PLC)

Security Management

Signaling H.235/TLS encryption, media SRTP encryption, support two-stream encryption
meeting access password, meeting control password, administrator password support national secret (SM2, SM3, SM4)
SIP/H323 call media stream support encryption algorithm AES256
physical privacy protection, support full HD main lens side turn, smart glasses head privacy protection cover

Interface

Audio input interface

Built-in array microphone 1 x 3.5mm

1×HD-AI

1×HDMI (Audio)

1 x Type-C (audio)

Audio output interface

1 x 3.5mm

1 x HDMI (audio)

Video input port

1 x built-in camera (1 channel 5X/12X smart C-bit view) 1 x HDMI

1×Type-C

Video output interface

2×HDMI

Other ports

1 x USB 3.0A port

1 x RJ45 (10/100/1000M LAN)

1 x RJ45 (connected to Touch)

1 x Wi-Fi (built in)

Conferencing capabilities

Language

Simplified Chinese, English, French, Japanese, Spanish, Portuguese, Italian, Thai, Turkish, Bulgari

Bandwidth

64kbps to 8Mbps

Maintenance Management

Maintenance methods

Terminal NMS: Supports SNMP and TR-069 protocols

WEB security management: built-in Web server, graphical maintenance diagnosis

Maintenance function

Terminal automatic sleep, wake up mechanism

Event logging, query display and export·Support factory Settings recovery

Built-in loopback function: local self-loop·Built-in sound and image test

Physical characteristics

Dimensions (length * width * height)

Terminal dimensions: 338mm*145mm*183mm

Packing size: 575mm*325mm*270mm

Net weight: 2.88Kg

Gross weight: 6.52Kg

Electrical characteristics

Operating voltage: 100V ~ 240VAC

Working frequency: 50Hz-60Hz

Maximum power consumption: 46W
