Enterprise high performance NVMe SSD ES3000-G V7 series

High performance
· Industry-leading performance specifications
· Sequential read and write up to 14.8GB/s, 11GB/s
· Random read and write up to 3.45 million IOPS, 460,000 IOPS
· 7μs Ultra-low write latency
High reliability
· Average trouble-free time is 2.5 million hours
· Self-developed FSP/LDPC algorithm, unrepairable error bit rate below 10-18
· Intelligent multi-stream technology effectively reduces write amplification and prolongs service life
High energy efficiency
· Energy efficiency than the industry leading, the actual business better power consumption
· Active power consumption less than 20W, 9 power intelligent dynamic adjustment, adapt to a variety of customer scenarios
Easy operation and maintenance
· Violent hot swap is supported
· Supports no-restart and internal online upgrade
· Complete log system, fast root cause location
· Firmware second-level activation, one-click repair

Technical Specification

Model number		ES3500-G V7	ES3600-G V7
Base specification	Capacity	1920/3840/7680GB/15.36TB	1600/3200/6400GB
	Form	U. 2,2.5 inches, 15mm thickness
	Port	PCIe 5.0 x4
	NVMe protocol	NVMe 2.0
	NAND Flash	3D TLC
Basic property	Sequential read	Up to 14800MB/s
	Sequential write	Up to 11000MB/s
	Random read	Up to 3450K IOPS（4KB）
	Random write	Up to 460K IOPS（4KB）	Up to 810K IOPS（4KB）
	Read delay	Up to 55 μs
	Write delay	Up to 7 μs
Life span	DWPD（5 years）	1	3
Reliability	Power failure protection	support
	Particle failure protection	support
	Mean time to failure (MTBF)	2.5 million hours
	Annual failure rate (AFR)	≤0.35%
	Bit error rate (UBER)	10⁻¹⁸
Peculiarity	Peculiarity	Supports 512/4096 series sector sizes Support online diagnosis and online refurbishment The NVMe command is used for upgrade
	Advanced features	Intelligent multi-stream/dynamic OP/Burst GC/NVMe2.0/SR-IOV/ atomic write /TRIM and so on

* The descriptions and information displayed in the product promotional materials are for reference only. The actual delivered product shall prevail. The final interpretation right belongs to GLORY.
